WRG32F2FBGLN

Rocker Switches

Manufacturer No:: WRG32F2FBGLN
Manufacture:: ZF Electronics
Datasheet:: WRG32F2FBGLN
Description:: SWITCH ROCKER DPST 16A 125V

In Stock

1481 pcs On sales

$1.89

Product Parameter

Circuit: DPST

Voltage Rating - AC: 125V

Features: -

Color - Actuator/Cap: Green

Packaging: Bulk

Current Rating (Amps): 16A (AC)

Part Status: Active

Operating Temperature: -20°C ~ 65°C

Actuator Type: Concave (Curved) - Illuminated

Panel Cutout Dimensions: Rectangular - 30.00mm x 22.00mm

Mounting Type: Panel Mount, Snap-In

Illumination Type, Color: Neon, Green

Electrical Life: 6,000 Cycles

Illumination Voltage (Nominal): 125 VAC

Mechanical Life: -

Switch Function: On-Off

Actuator Marking: O -

Termination Style: Quick Connect - 0.250" (6.3mm)

Series: WR

Ingress Protection: -
