VEL36US150-US-JA
AC DC Desktop, Wall Adapters
- Manufacturer No:
- VEL36US150-US-JA
- Manufacture:
- XP Power
- Datasheet:
- VEL36US150-US-JA
- Description:
- FIXED PLUG ADAPTER, 36W, OUTPUT
In Stock
114 pcs On sales
$18
Product Parameter
- Approvals
- CB, CCC
- Size / Dimension
- 3.70" L x 1.95" W x 2.11" H (94.0mm x 49.6mm x 53.6mm)
- Efficiency
- Level VI, CoC Tier 2
- Voltage - Output
- 15V
- Input Type
- Fixed Blade
- Operating Temperature
- 0°C ~ 60°C
- Cord Length
- 59" (1.50m)
- Current - Output (Max)
- 2.4A
- Part Status
- Active
- No Load Power Consumption
- 75mW (Max)
- Applications
- ITE (Commercial)
- Polarization
- Positive Center
- Power (Watts)
- 36W
- Input Connector
- NEMA 1-15P
- Form
- Wall Mount (Class II)
- Region Utilized
- North America
- Series
- VEL36 (36W)
- Voltage - Input
- 90 ~ 264 VAC
- Weight
- 0.342 lb (155.13 g)
- Output Connector
- Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 12.0mm
