6269250000
Terminal Blocks - Din Rail, Channel
- Manufacturer No:
- 6269250000
- Manufacture:
- Weidmuller
- Datasheet:
- 6269250000
- Description:
- DLD 2.5 BLUE WEMID
In Stock
100 pcs On sales
$7.42
Product Parameter
- Number of Levels
- 3
- Type
- Feed Through
- Stripping Length
- 7mm
- Color
- Blue
- Terminal - Width
- 6.2mm
- Series
- W
- Termination Style
- Screw
- Features
- -
- Number of Positions
- 6
- Fuse Type
- -
- Material - Insulation
- Thermoplastic, Wemid
- Part Status
- Active
- Wire Gauge or Range - AWG
- 12-26 AWG
- Current - UL
- 10A
- Wire Gauge or Range - mm²
- 0.5-4mm²
- Voltage - UL
- 300V
- Material Flammability Rating
- UL94 V-0
- Current - IEC
- 24A
- Voltage - IEC
- 250V
- Disconnect Type
- -
