SQJ402EP-T1_GE3
Transistors - FETs, MOSFETs - Single
- Manufacturer No:
- SQJ402EP-T1_GE3
- Manufacture:
- Vishay / Siliconix
- Package:
- 8-PowerTDFN
- Datasheet:
- SQJ402EP-T1_GE3
- Description:
- MOSFET N-CH 100V POWERPAK SO8L
In Stock
12239 pcs On sales
$0
Product Parameter
- Operating Temperature
- -55°C ~ 175°C (TJ)
- Rds On (Max) @ Id, Vgs
- 11mOhm @ 10A, 10V
- Series
- Automotive, AEC-Q101, TrenchFET®
- Power Dissipation (Max)
- 83W (Tc)
- FET Type
- N-Channel
- Supplier Device Package
- PowerPAK® SO-8
- Packaging
- Digi-Reel®
- Gate Charge (Qg) (Max) @ Vgs
- 51nC @ 10V
- Vgs (Max)
- ±20V
- Drain to Source Voltage (Vdss)
- 100V
- Technology
- MOSFET (Metal Oxide)
- Input Capacitance (Ciss) (Max) @ Vds
- 2289pF @ 40V
- FET Feature
- -
- Current - Continuous Drain (Id) @ 25°C
- 32A (Tc)
- Part Status
- Active
- Drive Voltage (Max Rds On, Min Rds On)
- 4.5V, 10V
- Mounting Type
- Surface Mount
- Package / Case
- 8-PowerTDFN
- Vgs(th) (Max) @ Id
- 2.5V @ 250µA
