IL1206AT
Optoisolators - Transistor, Photovoltaic Output
- Manufacturer No:
- IL1206AT
- Manufacture:
- Vishay / Semiconductor - Opto Division
- Package:
- 8-SOIC (0.154", 3.90mm Width)
- Datasheet:
- IL1206AT
- Description:
- OPTOISO 4KV TRANS W/BASE 8SOIC
In Stock
0 pcs On sales
$0.34
Product Parameter
- Mounting Type
- Surface Mount
- Voltage - Forward (Vf) (Typ)
- 1.3V
- Package / Case
- 8-SOIC (0.154", 3.90mm Width)
- Turn On / Turn Off Time (Typ)
- 3µs, 3µs
- Number of Channels
- 1
- Current - DC Forward (If) (Max)
- 60mA
- Voltage - Isolation
- 4000Vrms
- Vce Saturation (Max)
- 400mV
- Operating Temperature
- -55°C ~ 100°C
- Rise / Fall Time (Typ)
- -
- Series
- -
- Voltage - Output (Max)
- 70V
- Packaging
- Tape & Reel (TR)
- Supplier Device Package
- 8-SOIC
- Input Type
- DC
- Current - Output / Channel
- 50mA
- Output Type
- Transistor with Base
- Current Transfer Ratio (Max)
- 125% @ 10mA
- Part Status
- Active
- Current Transfer Ratio (Min)
- 63% @ 10mA
