PD42-1-1140-TMCL
Stepper Motors
- Manufacturer No:
- PD42-1-1140-TMCL
- Manufacture:
- TRINAMIC Motion Control GmbH
- Datasheet:
- PD42-1-1140-TMCL
- Description:
- STEPPER MOTOR HYBRID BIPOLAR 24V
In Stock
179 pcs On sales
$236.66
Product Parameter
- Accuracy
- ±5%
- Steps per Revolution
- 200
- Features
- Integrated Controller, Flatted Shaft
- Current Rating (Amps)
- 2A
- Approvals
- -
- Mounting Hole Spacing
- -
- Coil Type
- Bipolar
- Operating Temperature
- -
- Step Angle
- 1.8°
- Length - Shaft and Bearing
- 0.945" (24.00mm)
- Part Status
- Active
- Torque - Holding (oz-in / mNm)
- 31.2 / 220
- Rotor Inertia
- -
- NEMA Frame Size
- 17
- Voltage - Rated
- 24VDC
- Type
- Hybrid
- Diameter - Shaft
- 0.197" (5.00mm)
- Series
- PANdrive™
- Size / Dimension
- Square - 1.654" x 1.654" (42.00mm x 42.00mm)
- Weight
- 0.486 lb (220.45 g)
- Termination Style
- Wire Leads with Connector
