TB6612FNG,C,8,EL
PMIC - Motor Drivers, Controllers
- Manufacturer No:
- TB6612FNG,C,8,EL
- Manufacture:
- Toshiba Semiconductor and Storage
- Package:
- 24-LSSOP (0.220", 5.60mm Width)
- Datasheet:
- TB6612FNG,C,8,EL
- Description:
- IC MOTOR DRIVER 2.7V-5.5V 24SSOP
In Stock
30297 pcs On sales
$0
Product Parameter
- Part Status
- Active
- Operating Temperature
- -20°C ~ 85°C (TA)
- Applications
- General Purpose
- Supplier Device Package
- 24-SSOP
- Mounting Type
- Surface Mount
- Package / Case
- 24-LSSOP (0.220", 5.60mm Width)
- Voltage - Load
- 2.5V ~ 13.5V
- Step Resolution
- -
- Base Part Number
- TB6612
- Series
- -
- Current - Output
- 1A
- Function
- Driver - Fully Integrated, Control and Power Stage
- Voltage - Supply
- 2.7V ~ 5.5V
- Interface
- Parallel
- Motor Type - AC, DC
- Brushed DC
- Packaging
- Digi-Reel®
- Motor Type - Stepper
- -
- Technology
- Power MOSFET
- Output Configuration
- Half Bridge (4)
