7-1414967-8
Automotive Relays
- Manufacturer No:
- 7-1414967-8
- Manufacture:
- TE Connectivity Raychem Cable Protection
- Datasheet:
- 7-1414967-8
- Description:
- RELAY AUTO SPDT 30A 10V
In Stock
11303 pcs On sales
$4.75
Product Parameter
- Operate Time
- 3ms
- Release Time
- 1.5ms
- Mounting Type
- Through Hole
- Series
- Micro Relay K
- Coil Resistance
- 181 Ohms
- Features
- -
- Contact Material
- Silver Tin Oxide (AgSnO)
- Coil Type
- Non Latching
- Switching Voltage
- 10VDC - Nom
- Packaging
- Bulk
- Termination Style
- PC Pin
- Coil Power
- 552mW
- Must Operate Voltage
- 5.7 VDC
- Part Status
- Active
- Must Release Voltage
- 1.25 VDC
- Coil Current
- 55.0mA
- Operating Temperature
- -40°C ~ 105°C
- Coil Voltage
- 10VDC
- Contact Rating (Current)
- 30A
- Contact Form
- SPDT (1 Form C)
