KAP-11DG-24
Power Relays, Over 2 Amps
- Manufacturer No:
- KAP-11DG-24
- Manufacture:
- TE Connectivity Potter & Brumfield Relays
- Datasheet:
- KAP-11DG-24
- Description:
- RELAY GEN PURPOSE DPDT 10A 24V
In Stock
37 pcs On sales
$95.69
Product Parameter
- Coil Type
- Non Latching
- Switching Voltage
- 240VAC - Max
- Packaging
- Bulk
- Termination Style
- Plug In, 8 Pin (Octal)
- Relay Type
- General Purpose
- Must Operate Voltage
- 18 VDC
- Part Status
- Active
- Must Release Voltage
- -
- Seal Rating
- -
- Operating Temperature
- -45°C ~ 85°C
- Coil Current
- 51.0mA
- Contact Rating (Current)
- 10A
- Coil Voltage
- 24VDC
- Contact Form
- DPDT (2 Form C)
- Mounting Type
- Socketable
- Coil Insulation
- Class B
- Series
- KAP
- Coil Resistance
- 472 Ohms
- Features
- -
- Contact Material
- Silver Cadmium Oxide (AgCdO)
