55768-1
Terminals - Spade Connectors
- Manufacturer No:
- 55768-1
- Manufacture:
- TE Connectivity AMP Connectors
- Datasheet:
- 55768-1
- Description:
- CONN SPADE TERM 16-22AWG #8 RED
In Stock
20980 pcs On sales
$0.76
Product Parameter
- Color
- Red
- Contact Material
- Copper
- Series
- PIDG
- Length - Overall
- 0.895" (22.73mm)
- Features
- Serrated Termination
- Insulation Diameter
- 0.105" ~ 0.140" (2.67mm ~ 3.56mm)
- Packaging
- Cut Tape (CT)
- Width - Outer Edges
- 0.244" (6.20mm)
- Insulation
- Insulated
- Length - Termination
- 0.464" (11.79mm)
- Wire Gauge
- 16-22 AWG
- Material - Insulation
- Polyamide (PA), Nylon
- Part Status
- Active
- Tongue Inside Opening
- 0.164" (4.17mm)
- Termination
- Crimp
- Length - Ring Center to Termination
- 0.261" (6.63mm)
- Mounting Type
- Free Hanging (In-Line)
- Stud/Tab Size
- 8 Stud
- Terminal Type
- Spring, Snap
- Contact Finish
- Tin
