41473
Terminals - Spade Connectors
- Manufacturer No:
- 41473
- Manufacture:
- TE Connectivity AMP Connectors
- Datasheet:
- 41473
- Description:
- CONN SPADE TERM 14-18AWG #8
In Stock
43252 pcs On sales
$0.26
Product Parameter
- Mounting Type
- Free Hanging (In-Line)
- Stud/Tab Size
- 8 Stud
- Terminal Type
- Standard
- Contact Finish
- Tin
- Color
- -
- Contact Material
- Brass
- Series
- -
- Length - Overall
- 0.542" (13.77mm)
- Features
- -
- Insulation Diameter
- -
- Packaging
- Cut Tape (CT)
- Width - Outer Edges
- 0.275" (6.99mm)
- Insulation
- Non-Insulated
- Length - Termination
- 0.120" (3.05mm)
- Wire Gauge
- 14-18 AWG
- Material - Insulation
- -
- Part Status
- Active
- Tongue Inside Opening
- 0.171" (4.34mm)
- Termination
- Crimp
- Length - Ring Center to Termination
- 0.175" (4.45mm)
