RWS300B24
AC DC Converters
- Manufacturer No:
- RWS300B24
- Manufacture:
- TDK-Lambda Americas Inc.
- Datasheet:
- RWS300B24
- Description:
- AC/DC CONVERTER 24V 300W
In Stock
545 pcs On sales
$109
Product Parameter
- Number of Outputs
- 1
- Type
- Enclosed
- Voltage - Output 1
- 24V
- Series
- RWS-B (300W)
- Voltage - Output 2
- -
- Features
- Adjustable Output, DC Input Capable, Universal Input
- Voltage - Output 3
- -
- Approvals
- CE
- Voltage - Output 4
- -
- Efficiency
- 88%
- Voltage - Isolation
- 3kV
- Part Status
- Active
- Minimum Load Required
- -
- Applications
- ITE (Commercial)
- Operating Temperature
- -20°C ~ 70°C (With Derating)
- Mounting Type
- Chassis Mount
- Current - Output (Max)
- 12.5A
- Power (Watts)
- 300W
- Voltage - Input
- 85 ~ 265 VAC, 120 ~ 370 VDC
- Size / Dimension
- 6.70" L x 4.02" W x 1.61" H (170.0mm x 102.0mm x 41.0mm)
