PC44PQ40/40Z-12
Ferrite Cores
- Manufacturer No:
- PC44PQ40/40Z-12
- Manufacture:
- TDK Corporation
- Datasheet:
- PC44PQ40/40Z-12
- Description:
- FERRITE CORE 2PC SET
In Stock
31 pcs On sales
$2.84
Product Parameter
- Diameter
- -
- Material
- PC44
- Core Type
- PQ
- Tolerance
- ±25%
- Part Status
- Active
- Core Factor (ΣI/A) mm
- 0.508
- Gap
- Ungapped
- Supplier Device Package
- PQ 40 x 40
- Width
- 28.00mm
- Effective Area (Ae) mm²
- 201
- Finish
- Uncoated
- Effective Length (le) mm
- 102
- Height
- 39.75mm
- Effective Magnetic Volume (Ve) mm³
- 20500
- Length
- 40.50mm
- Series
- -
