FXUB66.01.0150C
RF Antennas
- Manufacturer No:
- FXUB66.01.0150C
- Manufacture:
- Taoglas Limited
- Datasheet:
- FXUB66.01.0150C
- Description:
- RF ANT 3.4GHZ FLAT PATCH SMA MAL
In Stock
337 pcs On sales
$7.24
Product Parameter
- Antenna Type
- Flat Patch
- Applications
- CDMA, GPS, GSM, LTE, UMTS, WLAN
- Height (Max)
- 0.008" (0.20mm)
- Gain
- 6.4dBi
- Mounting Type
- Adhesive
- VSWR
- 2.2
- Frequency Group
- Wide Band
- Series
- -
- Frequency Range
- 700MHz ~ 6GHz
- Features
- -
- Number of Bands
- 1
- Packaging
- Bulk
- Ingress Protection
- -
- Part Status
- Active
- RF Family/Standard
- Cellular, Navigation, WiFi
- Power - Max
- 5W
- Frequency (Center/Band)
- 3.4GHz
- Return Loss
- -7dB
- Termination
- SMA Male
