ME92251VX-000U-A99
DC Brushless Fans (BLDC)
- Manufacturer No:
- ME92251VX-000U-A99
- Manufacture:
- Sunon Fans
- Datasheet:
- ME92251VX-000U-A99
- Description:
- FAN AXIAL 92X25MM 12VDC WIRE
In Stock
70 pcs On sales
$13.71
Product Parameter
- Part Status
- Obsolete
- Current Rating (Amps)
- 0.190A
- Termination
- 2 Wire Leads
- Operating Temperature
- -
- Bearing Type
- Vapo-Bearing™
- RPM
- 3400 RPM
- Power (Watts)
- 2.28W
- Noise
- 37.5 dB(A)
- Voltage Range
- -
- Width
- 25.00mm
- Static Pressure
- 0.210 in H2O (52.3 Pa)
- Series
- MagLev® ME
- Voltage - Rated
- 12VDC
- Weight
- 0.227 lb (102.97 g)
- Lifetime @ Temp.
- -
- Air Flow
- 55.0 CFM (1.54m³/min)
- Material - Blade
- -
- Fan Type
- Tubeaxial
- Material - Frame
- -
- Features
- Auto Restart
- Size / Dimension
- Square - 92mm L x 92mm H
- Approvals
- CE, CUR, TUV, UL
- Ingress Protection
- -
