MC30100V1-000U-F99
DC Brushless Fans (BLDC)
- Manufacturer No:
- MC30100V1-000U-F99
- Manufacture:
- Sunon Fans
- Datasheet:
- MC30100V1-000U-F99
- Description:
- FAN AXIAL 30X10MM VAPO
In Stock
0 pcs On sales
$10.04
Product Parameter
- Weight
- 0.019 lb (8.62 g)
- Lifetime @ Temp.
- 60000 Hrs @ 40°C
- Air Flow
- 5.5 CFM (0.154m³/min)
- Material - Blade
- Polybutylene Terephthalate (PBT)
- Fan Type
- Tubeaxial
- Material - Frame
- Polybutylene Terephthalate (PBT)
- Features
- Auto Restart, Locked Rotor Sensor
- Size / Dimension
- Square - 30mm L x 30mm H
- Approvals
- CE, CUR, TUV, UL
- Ingress Protection
- -
- Part Status
- Active
- Current Rating (Amps)
- 0.120A
- Termination
- 3 Wire Leads
- Operating Temperature
- 14 ~ 158°F (-10 ~ 70°C)
- Bearing Type
- Vapo-Bearing™
- RPM
- 9500 RPM
- Power (Watts)
- 600mW
- Noise
- 23.0 dB(A)
- Voltage Range
- 2.5 ~ 6VDC
- Width
- 10.00mm
- Static Pressure
- 0.150 in H2O (37.3 Pa)
- Series
- MagLev® MC
- Voltage - Rated
- 5VDC
