BE05-1A66-P
Reed Relays
- Manufacturer No:
- BE05-1A66-P
- Manufacture:
- Standex-Meder Electronics
- Datasheet:
- BE05-1A66-P
- Description:
- RELAY REED SPST 0.5A 5V
In Stock
0 pcs On sales
$0
Product Parameter
- Contact Form
- SPST-NO (1 Form A)
- Operate Time
- 0.5ms
- Release Time
- 0.1ms
- Mounting Type
- Through Hole
- Series
- BE
- Coil Resistance
- 140 Ohms
- Features
- -
- Contact Material
- -
- Coil Type
- Non Latching
- Switching Voltage
- 200VAC, 200VDC - Max
- Packaging
- Tube
- Termination Style
- PC Pin
- Part Status
- Obsolete
- Must Operate Voltage
- 3.5 VDC
- Seal Rating
- Sealed - Fully
- Must Release Voltage
- 0.75 VDC
- Coil Current
- 35.8mA
- Operating Temperature
- -20°C ~ 70°C
- Coil Voltage
- 5VDC
- Contact Rating (Current)
- 500mA
