WT-2505
Alarms, Buzzers, and Sirens
- Manufacturer No:
- WT-2505
- Manufacture:
- Soberton, Inc.
- Datasheet:
- WT-2505
- Description:
- AUDIO MAGNETIC XDCR 3-7V TH
In Stock
68 pcs On sales
$3
Product Parameter
- Frequency
- 730Hz
- Driver Circuitry
- Transducer, Externally Driven
- Packaging
- Tray
- Size / Dimension
- 0.984" Dia (25.00mm)
- Input Type
- Zero-Peak Signal
- Height - Seated (Max)
- 0.512" (13.00mm)
- Technology
- Magnetic
- Operating Temperature
- -20°C ~ 60°C
- Part Status
- Active
- Sound Pressure Level (SPL)
- 85dB @ 6V, 10cm
- Termination
- PC Pins
- Mounting Type
- Through Hole
- Port Location
- Top
- Series
- WT
- Voltage Range
- 3 ~ 7V
- Ratings
- Washable
- Operating Mode
- Single Tone
- Duration
- -
- Voltage - Rated
- 6V
- Approvals
- -
- Current - Supply
- 80mA
