MCX7-J-P-HN-RA-TH1

Coaxial Connectors (RF)

Manufacturer No:: MCX7-J-P-HN-RA-TH1
Manufacture:: Samtec, Inc.
Datasheet:: MCX7-J-P-HN-RA-TH1
Description:: CONN MCX JACK R/A 75 OHM SOLDER

In Stock

25 pcs On sales

$6.15

Product Parameter

Cable Group: -

Number of Ports: 1

Part Status: Active

Mounting Feature: -

Body Material: Brass

Ingress Protection: -

Housing Color: Gold

Shield Termination: Solder

Mating Cycles: -

Contact Termination: Solder

Mounting Type: Through Hole, Right Angle

Dielectric Material: Polytetrafluoroethylene (PTFE)

Series: TRUE75™ MCX7

Connector Type: Jack, Female Socket

Operating Temperature: -65°C ~ 125°C

Features: -

Fastening Type: Snap-On

Center Contact Plating: Gold

Includes: -

Insertion Loss: -

Center Contact Material: Beryllium Copper

Impedance: 75Ohm

Voltage Rating: 170V

Packaging: Bag

Connector Style: MCX

Body Finish: Gold

Frequency - Max: 4.5GHz
