51K607-802N5
Coaxial Connectors (RF)
- Manufacturer No:
- 51K607-802N5
- Manufacture:
- Rosenberger
- Datasheet:
- 51K607-802N5
- Description:
- CONN BNC JACK STR 50OHM CRIMP
In Stock
50 pcs On sales
$10.01
Product Parameter
- Body Material
- Brass
- Ingress Protection
- -
- Housing Color
- Silver
- Shield Termination
- Crimp
- Mating Cycles
- 500
- Contact Termination
- Crimp
- Mounting Type
- Panel Mount
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Series
- -
- Connector Type
- Jack, Female Socket
- Operating Temperature
- -55°C ~ 155°C
- Features
- -
- Fastening Type
- Bayonet Lock
- Center Contact Plating
- Gold
- Includes
- 5 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Lockwasher, 1 Nut
- Insertion Loss
- -
- Center Contact Material
- Beryllium Copper
- Impedance
- 50Ohm
- Voltage Rating
- 400V
- Packaging
- Bulk
- Connector Style
- BNC
- Body Finish
- White Bronze
- Frequency - Max
- 10GHz
- Cable Group
- RG-174A, 188A, 316
- Number of Ports
- 1
- Part Status
- Active
- Mounting Feature
- Bulkhead - Front Side Nut
