PLV-025S048
LED Drivers
- Manufacturer No:
- PLV-025S048
- Manufacture:
- Qualtek
- Datasheet:
- PLV-025S048
- Description:
- LED DRIVER CV AC/DC 48V 520MA
In Stock
0 pcs On sales
$0
Product Parameter
- Topology
- AC DC Converter
- Voltage - Input (Max)
- 305VAC
- Approvals
- cULus
- Voltage - Input (Min)
- 90VAC
- Efficiency
- 84%
- Current - Output (Max)
- 520mA
- Part Status
- Obsolete
- Mounting Type
- Chassis Mount
- Power (Watts)
- 25W
- Type
- Constant Voltage
- Size / Dimension
- 3.15" L x 3.07" W x 1.06" H (80.0mm x 78.0mm x 27.0mm)
- Series
- PLV-025 (25W)
- Voltage - Output
- 48V
- Weight
- -
- Number of Outputs
- 1
- Dimming
- -
- Termination Style
- Wire Leads
- Ratings
- IP65
- Voltage - Isolation
- 2kV
- Features
- OCP, OTP, OVP, SCP
- Operating Temperature
- -25°C ~ 50°C
