AUM-5047L-3-R
Microphones
- Manufacturer No:
- AUM-5047L-3-R
- Manufacture:
- PUI Audio, Inc.
- Datasheet:
- AUM-5047L-3-R
- Description:
- MICROPHONE -47 DB 1.5 VDC 680 OH
In Stock
2227 pcs On sales
$1.72
Product Parameter
- Output Type
- Analog
- Part Status
- Active
- Sensitivity
- -47dB ±4dB
- Termination
- Solder Pads
- Height (Max)
- 0.205" (5.20mm)
- Type
- Electret Condenser
- Port Location
- Top
- Shape
- Circular
- Voltage Range
- 1.5V ~ 10V
- Series
- AUM
- Frequency Range
- 50Hz ~ 16kHz
- Direction
- Unidirectional
- Voltage - Rated
- 1.5V
- Impedance
- 680 Ohms
- Current - Supply
- 500µA
- Packaging
- Bulk
- Size / Dimension
- 0.382" Dia (9.70mm)
- S/N Ratio
- 55dB
