72984
Coaxial Connectors (RF)
- Manufacturer No:
- 72984
- Manufacture:
- Pomona Electronics
- Datasheet:
- 72984
- Description:
- CONN SMB JACK STR 50 OHM CRIMP
In Stock
60 pcs On sales
$9.89
Product Parameter
- Part Status
- Active
- Mounting Feature
- -
- Body Material
- Brass
- Ingress Protection
- -
- Housing Color
- Gold
- Shield Termination
- Crimp
- Mating Cycles
- 500
- Contact Termination
- Crimp
- Mounting Type
- Free Hanging (In-Line)
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Series
- -
- Connector Type
- Jack, Male Pin
- Operating Temperature
- -65°C ~ 165°C
- Features
- -
- Fastening Type
- Snap-On
- Center Contact Plating
- Gold
- Includes
- 3 pcs - 1 Connector, 1 Ferrule, 1 Heat Shrink
- Insertion Loss
- -
- Center Contact Material
- Beryllium Copper
- Impedance
- 50Ohm
- Voltage Rating
- 250V
- Packaging
- Bulk
- Connector Style
- SMB
- Body Finish
- Gold
- Frequency - Max
- 3GHz
- Cable Group
- RG-174, 188, 316
- Number of Ports
- 1
