5018-2
Banana and Tip Connectors - Binding Posts
- Manufacturer No:
- 5018-2
- Manufacture:
- Pomona Electronics
- Datasheet:
- 5018-2
- Description:
- CONN BIND POST HEX RED
In Stock
194 pcs On sales
$15.49
Product Parameter
- Nut Material
- Steel
- Plating - Body
- Gold
- Voltage Rating
- 30VAC/60VDC
- Material - Body
- Brass
- Type
- Standard
- Panel Thickness
- -
- Color
- Red
- Termination Thread
- -
- Series
- -
- Cross Hole Diameter
- 0.100" (2.54mm)
- Head Size
- 0.480" OD (12.19mm)
- Current Rating (Amps)
- 30A
- Head Style
- Hex
- Material - Insulation
- Polyamide (PA), Nylon
- Nut Plating
- -
- Part Status
- Active
- Termination
- Threaded and Turret
