3074004
Terminal Blocks - Din Rail, Channel
- Manufacturer No:
- 3074004
- Manufacture:
- Phoenix Contact
- Datasheet:
- 3074004
- Description:
- CONN TERM BLK DISCONN 10-26AWG
In Stock
0 pcs On sales
$10.74
Product Parameter
- Disconnect Type
- Switch, Lever
- Number of Levels
- 2; 1 Grounded
- Type
- Disconnect, Isolated
- Stripping Length
- 9mm
- Color
- Black
- Terminal - Width
- 6.2mm
- Series
- CLIPLINE UT
- Termination Style
- Screw
- Features
- -
- Number of Positions
- 3
- Fuse Type
- -
- Material - Insulation
- Polyamide (PA), Nylon
- Part Status
- Active
- Wire Gauge or Range - AWG
- 10-26 AWG
- Current - UL
- 16A
- Wire Gauge or Range - mm²
- 0.14-6mm²
- Voltage - UL
- 600V
- Material Flammability Rating
- UL94 V-0
- Current - IEC
- 20A
- Voltage - IEC
- 500V
