3033058
Terminal Blocks - Din Rail, Channel
- Manufacturer No:
- 3033058
- Manufacture:
- Phoenix Contact
- Datasheet:
- 3033058
- Description:
- CONN TERM BLK FEED THRU 10-26AWG
In Stock
0 pcs On sales
$2.2
Product Parameter
- Part Status
- Active
- Wire Gauge or Range - AWG
- 10-26 AWG
- Current - UL
- 30A
- Wire Gauge or Range - mm²
- 0.14-6mm²
- Voltage - UL
- 600V
- Material Flammability Rating
- UL94 V-0
- Current - IEC
- 32A
- Voltage - IEC
- 800V
- Disconnect Type
- -
- Number of Levels
- 1
- Type
- Feed Through
- Stripping Length
- 10mm
- Color
- Gray
- Terminal - Width
- 6.2mm
- Series
- CLIPLINE STU
- Termination Style
- Push In Spring; Screw
- Features
- -
- Number of Positions
- 3
- Fuse Type
- -
- Material - Insulation
- Polyamide (PA), Nylon
