PN22-2F-M
Terminals - Spade Connectors
- Manufacturer No:
- PN22-2F-M
- Manufacture:
- Panduit Corp
- Datasheet:
- PN22-2F-M
- Description:
- CONN SPADE TERM 22-26AWG #2 YEL
In Stock
0 pcs On sales
$0
Product Parameter
- Part Status
- Obsolete
- Tongue Inside Opening
- 0.090" (2.28mm)
- Termination
- Crimp
- Length - Ring Center to Termination
- -
- Mounting Type
- Free Hanging (In-Line)
- Stud/Tab Size
- 2 Stud
- Terminal Type
- Standard, Circular
- Contact Finish
- Tin
- Color
- Yellow
- Contact Material
- Copper
- Series
- Pan-Term®
- Length - Overall
- 0.660" (16.76mm)
- Features
- -
- Insulation Diameter
- 0.090" (2.29mm)
- Packaging
- Bulk
- Width - Outer Edges
- 0.200" (5.08mm)
- Insulation
- Insulated
- Length - Termination
- -
- Wire Gauge
- 22-26 AWG
- Material - Insulation
- Polyamide (PA), Nylon
