LY G5AP-CXDX-36-1-100-R18-Z
LED Lighting - Color
- Manufacturer No:
- LY G5AP-CXDX-36-1-100-R18-Z
- Manufacture:
- OSRAM Opto Semiconductors, Inc.
- Package:
- 4-SMD, Gull Wing
- Datasheet:
- LY G5AP-CXDX-36-1-100-R18-Z
- Description:
- LED TOPLED ADV 590NM YLW 4-PLCC
In Stock
0 pcs On sales
$0
Product Parameter
- Mounting Type
- Surface Mount
- Viewing Angle
- 145°
- Current - Test
- 100mA
- Package / Case
- 4-SMD, Gull Wing
- Size / Dimension
- 0.134" L x 0.134" W (3.40mm x 3.40mm)
- Temperature - Test
- 25°C
- Color
- Yellow
- Height - Seated (Max)
- 0.089" (2.27mm)
- Series
- Advanced Power TOPLED®
- Supplier Device Package
- 4-PLCC
- Packaging
- Digi-Reel®
- Lumens/Watt @ Current - Test
- 69 lm/W
- Wavelength
- 589nm (583nm ~ 595nm)
- Voltage - Forward (Vf) (Typ)
- 2.17V
- Part Status
- Discontinued at Digi-Key
- Thermal Resistance of Package
- 40°C/W
- Current - Max
- 200mA
- Flux @ Current/Temperature - Test
- 15lm (12lm ~ 18lm)
