LCG H9RN-MYNY-1
LED Lighting - COBs, Engines, Modules, Strips
- Manufacturer No:
- LCG H9RN-MYNY-1
- Manufacture:
- OSRAM Opto Semiconductors, Inc.
- Datasheet:
- LCG H9RN-MYNY-1
- Description:
- LED COB OSTAR GREEN 550NM SQUARE
In Stock
1751 pcs On sales
$0
Product Parameter
- Wavelength
- 550nm (500nm ~ 600nm)
- Flux @ Current/Temperature - Test
- 300lm (210lm ~ 390lm)
- Part Status
- Active
- Configuration
- Square
- Current - Max
- 1A
- Type
- Chip On Board (COB)
- Viewing Angle
- 120°
- Color
- Green
- Current - Test
- 700mA
- Height
- 0.50mm
- Size / Dimension
- 3.75mm L x 3.75mm W
- Series
- Ostar
- Temperature - Test
- 25°C
- CCT (K)
- -
- CRI (Color Rendering Index)
- -
- Features
- -
- Light Emitting Surface (LES)
- 0.98mm L x 0.98mm W
- Lens Type
- Flat
- Lumens/Watt @ Current - Test
- 130 lm/W
- Packaging
- Digi-Reel®
- Voltage - Forward (Vf) (Typ)
- 3.3V
