KW CELNM1.TG-Z5NF6-EBVFFCBB46-15B3-A-S
LED Lighting - White
- Manufacturer No:
- KW CELNM1.TG-Z5NF6-EBVFFCBB46-15B3-A-S
- Manufacture:
- OSRAM Opto Semiconductors, Inc.
- Package:
- 2-SMD, No Lead Exposed Pad
- Datasheet:
- KW CELNM1.TG-Z5NF6-EBVFFCBB46-15B3-A-S
- Description:
- OSTAR COMPACT
In Stock
3494 pcs On sales
$0
Product Parameter
- Current - Test
- 1A
- Package / Case
- 2-SMD, No Lead Exposed Pad
- Size / Dimension
- 0.075" L x 0.059" W (1.90mm x 1.50mm)
- Height - Seated (Max)
- 0.030" (0.77mm)
- Color
- White
- Supplier Device Package
- SMD
- Series
- OSLON® Compact PL
- CRI (Color Rendering Index)
- -
- CCT (K)
- -
- Flux @ 25°C, Current - Test
- 374lm (297lm ~ 450lm)
- Packaging
- Digi-Reel®
- Flux @ 85°C, Current - Test
- -
- Part Status
- Active
- Lumens/Watt @ Current - Test
- 125 lm/W
- Current - Max
- 1.5A
- Voltage - Forward (Vf) (Typ)
- 3V
- Mounting Type
- Surface Mount
- Thermal Resistance of Package
- 4.6°C/W
- Viewing Angle
- 120°
