9994-0-00-15-00-00-03-0

Terminals - PC Pin, Single Post Connectors

Manufacturer No:: 9994-0-00-15-00-00-03-0
Manufacture:: Mill-Max Manufacturing Corp.
Datasheet:: 9994-0-00-15-00-00-03-0
Description:: .280" LONG PRESS-FIT PIN

In Stock

5000 pcs On sales

$0.17

Product Parameter

Packaging: Bulk

Length - Overall: 0.280" (7.11mm)

Insulation: Non-Insulated

Length - Above Flange: 0.150" (3.81mm)

Part Status: Active

Length - Below Flange: 0.115" (2.92mm)

Termination: Press-Fit

Material - Insulation: -

Mounting Type: Through Hole

Mounting Hole Diameter: 0.033" (0.84mm)

Terminal Type: PC Pin

Pin Size - Above Flange: 0.020" (0.51mm) Dia

Contact Finish: Gold

Pin Size - Below Flange: 0.030" (0.76mm) Dia

Terminal Style: Double End

Contact Finish Thickness: 10.0µin (0.25µm)

Board Thickness: -

Flange Diameter: 0.045" (1.14mm)

Contact Material: Brass Alloy

Series: 9994

Insulation Color: -
