6218-0-00-15-00-00-03-0
Terminals - PC Pin, Single Post Connectors
- Manufacturer No:
- 6218-0-00-15-00-00-03-0
- Manufacture:
- Mill-Max Manufacturing Corp.
- Datasheet:
- 6218-0-00-15-00-00-03-0
- Description:
- CONN PC PIN CIRC 0.019DIA GOLD
In Stock
1304 pcs On sales
$0.18
Product Parameter
- Part Status
- Active
- Length - Below Flange
- 0.182" (4.62mm)
- Termination
- Press-Fit
- Material - Insulation
- -
- Mounting Type
- Through Hole
- Mounting Hole Diameter
- 0.057" (1.45mm)
- Terminal Type
- PC Pin
- Pin Size - Above Flange
- 0.019" (0.48mm) Dia
- Contact Finish
- Gold
- Pin Size - Below Flange
- 0.020" (0.51mm) Dia
- Terminal Style
- Double End
- Contact Finish Thickness
- 10.0µin (0.25µm)
- Board Thickness
- -
- Flange Diameter
- 0.060" (1.52mm)
- Contact Material
- Brass Alloy
- Series
- 6218
- Insulation Color
- -
- Packaging
- Bulk
- Length - Overall
- 0.399" (10.13mm)
- Insulation
- Non-Insulated
- Length - Above Flange
- 0.142" (3.61mm)
