5240-0-00-15-00-00-33-0

Terminals - PC Pin, Single Post Connectors

Manufacturer No:: 5240-0-00-15-00-00-33-0
Manufacture:: Mill-Max Manufacturing Corp.
Datasheet:: 5240-0-00-15-00-00-33-0
Description:: CONN PC PIN CIRC 0.025DIA GOLD

In Stock

13974 pcs On sales

$0.59

Product Parameter

Part Status: Active

Length - Below Flange: -

Termination: Solder

Material - Insulation: -

Mounting Type: Through Hole

Mounting Hole Diameter: 0.029" (0.74mm)

Terminal Type: PC Pin

Pin Size - Above Flange: 0.025" (0.64mm) Dia

Contact Finish: Gold

Pin Size - Below Flange: -

Terminal Style: Single End, Nail Head

Contact Finish Thickness: 10.0µin (0.25µm)

Board Thickness: -

Flange Diameter: 0.062" (1.57mm)

Contact Material: Brass Alloy

Series: 5240

Insulation Color: -

Packaging: Bulk

Length - Overall: 0.240" (6.10mm)

Insulation: Non-Insulated

Length - Above Flange: 0.232" (5.89mm)
