5137-0-00-15-00-00-38-0

Terminals - PC Pin, Single Post Connectors

Manufacturer No:: 5137-0-00-15-00-00-38-0
Manufacture:: Mill-Max Manufacturing Corp.
Datasheet:: 5137-0-00-15-00-00-38-0
Description:: CONN PC PIN CIRC 0.018DIA GOLD

In Stock

21527 pcs On sales

$0.6

Product Parameter

Board Thickness: -

Flange Diameter: 0.050" (1.27mm)

Contact Material: Brass Alloy

Series: 5137

Insulation Color: -

Packaging: Bulk

Length - Overall: 0.320" (8.13mm)

Insulation: Non-Insulated

Length - Above Flange: 0.300" (7.62mm)

Part Status: Active

Length - Below Flange: -

Termination: Solder

Material - Insulation: -

Mounting Type: Through Hole

Mounting Hole Diameter: 0.022" (0.56mm)

Terminal Type: PC Pin

Pin Size - Above Flange: 0.018" (0.46mm) Dia

Contact Finish: Gold

Pin Size - Below Flange: -

Terminal Style: Single End, Nail Head

Contact Finish Thickness: 10.0µin (0.25µm)
