1134-0-18-15-47-27-10-0

Terminals - PC Pin Receptacles, Socket Connectors

Manufacturer No:: 1134-0-18-15-47-27-10-0
Manufacture:: Mill-Max Manufacturing Corp.
Datasheet:: 1134-0-18-15-47-27-10-0
Description:: CONN PIN RCPT .025-.037 PRESSFIT

In Stock

18926 pcs On sales

$0.55

Product Parameter

Flange Diameter: 0.070" (1.77mm)

Insertion Force: -

Series: 1134

Contact Material: Beryllium Copper

Features: -

Length - Overall: 0.450" (11.43mm)

Packaging: Bulk

Pin Hole Diameter: 0.051" (1.30mm)

Tail Type: Solder Cup

Accepts Pin Diameter: 0.025" ~ 0.037" (0.64mm ~ 0.94mm)

Part Status: Active

Operating Temperature: -55°C ~ 125°C

Termination: Press-Fit

Mounting Hole Diameter: 0.061" (1.55mm)

Socket Depth: 0.200" (5.08mm)

Accepts Square Pin Size: 0.025" (0.64mm)

Tail Diameter: -

Contact Finish Thickness: 10.0µin (0.25µm)

Contact Finish: Gold

Board Thickness: -
