UF318AAA23-H1C4A-L32
AC Fans
- Manufacturer No:
- UF318AAA23-H1C4A-L32
- Manufacture:
- Mechatronics Fan Group
- Datasheet:
- UF318AAA23-H1C4A-L32
- Description:
- FAN IMP MTRZ 318X154.4MM 230VAC
In Stock
2 pcs On sales
$158.25
Product Parameter
- RPM
- 1580 RPM
- Power (Watts)
- 160W
- Noise
- 66.0 dB(A)
- Voltage Range
- -
- Width
- 154.4mm
- Static Pressure
- 1.600 in H2O (398.6 Pa)
- Series
- UF318AAA
- Voltage - Rated
- 230VAC
- Weight
- 8.3 lbs (3.8 kg)
- Lifetime @ Temp.
- -
- Air Flow
- 1165.0 CFM (32.62m³/min)
- Material - Blade
- Steel
- Fan Type
- Motorized Impellers
- Material - Frame
- Steel
- Features
- Permanent Split Capacitor Motor, Thermal Overload Protector (TOP)
- Size / Dimension
- Round - 318mm Dia
- Approvals
- CE, cUL, TUV, UL
- Ingress Protection
- -
- Part Status
- Active
- Current Rating (Amps)
- 0.700A
- Termination
- 2 Wire Leads
- Operating Temperature
- -4 ~ 158°F (-20 ~ 70°C)
- Bearing Type
- Ball
