MC8038H24B-FSR
DC Brushless Fans (BLDC)
- Manufacturer No:
- MC8038H24B-FSR
- Manufacture:
- Mechatronics Fan Group
- Datasheet:
- MC8038H24B-FSR
- Description:
- FAN AXIAL 80X38MM 24VDC
In Stock
0 pcs On sales
$12.28
Product Parameter
- Air Flow
- 69.9 CFM (1.96m³/min)
- Material - Frame
- Polybutylene Terephthalate (PBT)
- Fan Type
- Tubeaxial
- Size / Dimension
- Square - 80mm L x 80mm H
- Features
- Thermal Overload Protector (TOP)
- Ingress Protection
- -
- Approvals
- cUL, TUV, UL
- Current Rating (Amps)
- 0.330A
- Part Status
- Active
- Operating Temperature
- -
- Termination
- 2 Wire Leads
- Bearing Type
- Ball
- RPM
- 5000 RPM
- Voltage Range
- -
- Noise
- 48.2 dB(A)
- Static Pressure
- 0.610 in H2O (151.9 Pa)
- Width
- 38.00mm
- Voltage - Rated
- 24VDC
- Series
- MC8038
- Lifetime @ Temp.
- -
- Weight
- 0.397 lb (180.08 g)
- Material - Blade
- Polybutylene Terephthalate (PBT)
