G5015H24B-RSR
DC Brushless Fans (BLDC)
- Manufacturer No:
- G5015H24B-RSR
- Manufacture:
- Mechatronics Fan Group
- Datasheet:
- G5015H24B-RSR
- Description:
- FAN AXIAL 50X15MM 24VDC
In Stock
0 pcs On sales
$9.08
Product Parameter
- Series
- G5015
- Lifetime @ Temp.
- -
- Weight
- 0.077 lb (34.93 g)
- Material - Blade
- Polybutylene Terephthalate (PBT)
- Air Flow
- 13.0 CFM (0.364m³/min)
- Material - Frame
- Polybutylene Terephthalate (PBT)
- Fan Type
- Tubeaxial
- Size / Dimension
- Square - 50mm L x 50mm H
- Features
- Thermal Overload Protector (TOP)
- Ingress Protection
- -
- Approvals
- CE, cUL, TUV, UL
- Current Rating (Amps)
- 0.180A
- Part Status
- Active
- Operating Temperature
- -
- Termination
- 2 Wire Leads
- Bearing Type
- Ball
- RPM
- 5500 RPM
- Voltage Range
- -
- Noise
- 29.0 dB(A)
- Static Pressure
- 0.170 in H2O (42.3 Pa)
- Width
- 15.00mm
- Voltage - Rated
- 24VDC
