TDR-960-48
AC DC Converters
- Manufacturer No:
- TDR-960-48
- Manufacture:
- MEAN WELL USA Inc.
- Datasheet:
- TDR-960-48
- Description:
- AC/DC CONVERTER 48V 960W
In Stock
12 pcs On sales
$227.41
Product Parameter
- Voltage - Input
- 340 ~ 550 VAC (3PH), 480 ~ 780 VDC
- Size / Dimension
- 5.91" L x 4.33" W x 4.93" H (150.0mm x 110.0mm x 125.2mm)
- Number of Outputs
- 1
- Type
- Enclosed
- Voltage - Output 1
- 48V
- Series
- TDR-960 (960W)
- Voltage - Output 2
- -
- Features
- Adjustable Output, PFC
- Voltage - Output 3
- -
- Approvals
- CB, CE, cULus
- Voltage - Output 4
- -
- Efficiency
- 94.5%
- Voltage - Isolation
- 3kV
- Part Status
- Active
- Minimum Load Required
- No
- Applications
- Industrial, ITE (Commercial)
- Operating Temperature
- -30°C ~ 70°C (With Derating)
- Mounting Type
- DIN Rail
- Current - Output (Max)
- 20A
- Power (Watts)
- 960W
