HSP-150-5
AC DC Converters
- Manufacturer No:
- HSP-150-5
- Manufacture:
- MEAN WELL USA Inc.
- Datasheet:
- HSP-150-5
- Description:
- AC/DC CONVERTER 5V 150W
In Stock
0 pcs On sales
$0
Product Parameter
- Part Status
- Obsolete
- Minimum Load Required
- No
- Applications
- ITE (Commercial)
- Operating Temperature
- -30°C ~ 70°C (With Derating)
- Mounting Type
- Chassis Mount
- Current - Output (Max)
- 30A
- Power (Watts)
- 150W (200W Forced Air)
- Voltage - Input
- 90 ~ 264 VAC, 127 ~ 370 VDC
- Size / Dimension
- 8.66" L x 2.44" W x 1.26" H (220.0mm x 62.0mm x 32.0mm)
- Number of Outputs
- 1
- Type
- Enclosed, Conformal Coated
- Voltage - Output 1
- 5V
- Series
- HSP-150 (150W)
- Voltage - Output 2
- -
- Features
- Adjustable Output, PFC, Remote Sense, Universal Input
- Voltage - Output 3
- -
- Approvals
- CB, CE, cURus, TUV
- Voltage - Output 4
- -
- Efficiency
- 90%
- Voltage - Isolation
- 3kV
