HI3-0201-5+
Interface - Analog Switches, Multiplexers, Demultiplexers
- Manufacturer No:
- HI3-0201-5+
- Manufacture:
- Maxim Integrated
- Package:
- 16-DIP (0.300", 7.62mm)
- Datasheet:
- HI3-0201-5+
- Description:
- IC SWITCH ANALOG QUAD CMOS 16DIP
In Stock
215 pcs On sales
$5.43
Product Parameter
- Switch Circuit
- SPST - NC
- Channel Capacitance (CS(off), CD(off))
- 5pF, 5pF
- Charge Injection
- 20pC
- Number of Circuits
- 4
- Operating Temperature
- 0°C ~ 70°C (TA)
- Supplier Device Package
- 16-PDIP
- On-State Resistance (Max)
- 80Ohm
- Series
- -
- Voltage - Supply, Dual (V±)
- ±4.5V ~ 18V
- Crosstalk
- -90dB @ 100kHz
- Switch Time (Ton, Toff) (Max)
- 500ns, 350ns
- Packaging
- Tube
- Voltage - Supply, Single (V+)
- 5V ~ 30V
- Part Status
- Last Time Buy
- Current - Leakage (IS(off)) (Max)
- 10nA
- -3db Bandwidth
- -
- Multiplexer/Demultiplexer Circuit
- 1:1
- Package / Case
- 16-DIP (0.300", 7.62mm)
- Channel-to-Channel Matching (ΔRon)
- -
