LCD0821
Display Modules - LCD, OLED Character and Numeric
- Manufacturer No:
- LCD0821
- Manufacture:
- Matrix Orbital
- Datasheet:
- LCD0821
- Description:
- LCD ALPHA/NUM DISPL 8X2 YW/GN BK
In Stock
110 pcs On sales
$39.95
Product Parameter
- Dot Size
- 0.56mm W x 0.66mm H
- Voltage - Supply
- 5V
- Backlight
- LED - Yellow/Green
- Outline L x W x H
- 58.00mm x 32.00mm x 26.80mm
- Interface
- I²C, RS-232, TTL
- Number of Characters
- 16
- Text Color
- Black
- Operating Temperature
- 0°C ~ 50°C
- Part Status
- Active
- Display Mode
- Transmissive
- Display Type
- TN - Twisted Nematic
- Viewing Area
- 38.00mm L x 16.00mm W
- Character Size
- 5.56mm H x 2.96mm W
- Display Format
- 8 x 2
- Background Color
- Green
- Series
- LCD0821
- Character Format
- 5 x 8 Dots
