S6055NRP
Thyristors - SCRs
- Manufacturer No:
- S6055NRP
- Manufacture:
- Littelfuse Inc.
- Package:
- TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Datasheet:
- S6055NRP
- Description:
- SCR NON-ISOLATED 600V 55A D2PAK
In Stock
1668 pcs On sales
$0
Product Parameter
- Operating Temperature
- -40°C ~ 125°C
- Supplier Device Package
- TO-263 (D2Pak)
- Current - Hold (Ih) (Max)
- 60mA
- Current - Off State (Max)
- 10µA
- Voltage - On State (Vtm) (Max)
- 1.8V
- Series
- -
- Current - Gate Trigger (Igt) (Max)
- 40mA
- SCR Type
- Standard Recovery
- Current - On State (It (AV)) (Max)
- 35A
- Packaging
- Digi-Reel®
- Voltage - Gate Trigger (Vgt) (Max)
- 1.5V
- Part Status
- Active
- Current - On State (It (RMS)) (Max)
- 55A
- Mounting Type
- Surface Mount
- Current - Non Rep. Surge 50, 60Hz (Itsm)
- 550A, 650A
- Package / Case
- TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Voltage - Off State
- 600V
