RXE110-1
PTC Resettable Fuses
- Manufacturer No:
- RXE110-1
- Manufacture:
- Littelfuse Inc.
- Package:
- Radial, Disc
- Datasheet:
- RXE110-1
- Description:
- PTC RESET FUSE 72V 1.1A RADIAL
In Stock
0 pcs On sales
$0
Product Parameter
- Mounting Type
- Through Hole
- Voltage - Max
- 72V
- Package / Case
- Radial, Disc
- Type
- Polymeric
- Thickness (Max)
- -
- Series
- PolySwitch®, RXE
- Size / Dimension
- 0.504" Dia x 0.118" T (12.80mm x 3.00mm)
- Ratings
- -
- Current - Trip (It)
- 2.2A
- Approvals
- CSA, TUV, UL
- Height - Seated (Max)
- 0.689" (17.50mm)
- Packaging
- Bulk
- Operating Temperature
- -
- Part Status
- Obsolete
- Current - Hold (Ih) (Max)
- 1.1A
- Lead Spacing
- 0.199" (5.05mm)
- Resistance - Initial (Ri) (Min)
- 150 mOhms
- Time to Trip
- 8.2s
- Resistance - Post Trip (R1) (Max)
- 380 mOhms
- Current - Max
- 40A
