RHE400
PTC Resettable Fuses
- Manufacturer No:
- RHE400
- Manufacture:
- Littelfuse Inc.
- Package:
- Radial, Disc
- Datasheet:
- RHE400
- Description:
- PTC RESET FUSE 16V 4A RADIAL
In Stock
0 pcs On sales
$0
Product Parameter
- Type
- Polymeric
- Thickness (Max)
- -
- Series
- PolySwitch®
- Size / Dimension
- 0.449" L x 0.118" W (11.40mm x 3.00mm)
- Ratings
- -
- Current - Trip (It)
- 7A
- Approvals
- CSA, TUV, UR
- Height - Seated (Max)
- 0.709" (18.00mm)
- Packaging
- Bulk
- Operating Temperature
- -
- Part Status
- Obsolete
- Current - Hold (Ih) (Max)
- 4A
- Lead Spacing
- 0.199" (5.05mm)
- Resistance - Initial (Ri) (Min)
- 18 mOhms
- Time to Trip
- 8s
- Resistance - Post Trip (R1) (Max)
- 44 mOhms
- Current - Max
- 100A
- Mounting Type
- Through Hole
- Voltage - Max
- 16V
- Package / Case
- Radial, Disc
