1999-3
Terminals - PC Pin, Single Post Connectors
- Manufacturer No:
- 1999-3
- Manufacture:
- Keystone Electronics
- Datasheet:
- 1999-3
- Description:
- CONN PC PIN CIRC 0.020DIA GOLD
In Stock
4028 pcs On sales
$0.43
Product Parameter
- Contact Material
- Brass
- Series
- -
- Insulation Color
- -
- Packaging
- Bulk
- Length - Overall
- 0.545" (13.84mm)
- Insulation
- Non-Insulated
- Length - Above Flange
- 0.425" (10.80mm)
- Part Status
- Active
- Length - Below Flange
- 0.100" (2.54mm)
- Termination
- Solder
- Material - Insulation
- -
- Mounting Type
- Through Hole
- Mounting Hole Diameter
- 0.024" (0.61mm)
- Terminal Type
- PC Pin
- Pin Size - Above Flange
- 0.020" (0.51mm) Dia
- Contact Finish
- Gold
- Pin Size - Below Flange
- 0.020" (0.51mm) Dia
- Terminal Style
- Single End
- Contact Finish Thickness
- 10.0µin (0.25µm)
- Board Thickness
- 0.093" (2.36mm)
- Flange Diameter
- 0.045" (1.14mm)
