SX50U-15S
AC DC Converters
- Manufacturer No:
- SX50U-15S
- Manufacture:
- Kaga Electronics USA
- Datasheet:
- SX50U-15S
- Description:
- AC/DC CONVERTER 15V 50W
In Stock
0 pcs On sales
$0
Product Parameter
- Voltage - Input
- 85 ~ 132 VAC
- Size / Dimension
- 4.69" L x 3.35" W x 1.46" H (119.0mm x 85.0mm x 37.0mm)
- Number of Outputs
- 1
- Type
- Enclosed
- Voltage - Output 1
- 15V
- Series
- SX50U (50W)
- Voltage - Output 2
- -
- Features
- Adjustable Output
- Voltage - Output 3
- -
- Approvals
- CSA, UL
- Voltage - Output 4
- -
- Efficiency
- 78%
- Voltage - Isolation
- 2kV
- Part Status
- Obsolete
- Minimum Load Required
- -
- Applications
- ITE (Commercial)
- Operating Temperature
- 0°C ~ 60°C
- Mounting Type
- Chassis Mount
- Current - Output (Max)
- 3.4A
- Power (Watts)
- 50W
