IXTN170P10P
Transistors - FETs, MOSFETs - Single
- Manufacturer No:
- IXTN170P10P
- Manufacture:
- IXYS
- Package:
- SOT-227-4, miniBLOC
- Datasheet:
- IXTN170P10P
- Description:
- MOSFET P-CH 100V 170A SOT227
In Stock
307 pcs On sales
$25.09
Product Parameter
- Packaging
- Tube
- Gate Charge (Qg) (Max) @ Vgs
- 240nC @ 10V
- Vgs (Max)
- ±20V
- Drain to Source Voltage (Vdss)
- 100V
- Technology
- MOSFET (Metal Oxide)
- Input Capacitance (Ciss) (Max) @ Vds
- 12600pF @ 25V
- FET Feature
- -
- Current - Continuous Drain (Id) @ 25°C
- 170A (Tc)
- Part Status
- Active
- Drive Voltage (Max Rds On, Min Rds On)
- 10V
- Mounting Type
- Chassis Mount
- Package / Case
- SOT-227-4, miniBLOC
- Vgs(th) (Max) @ Id
- 4V @ 1mA
- Operating Temperature
- -55°C ~ 150°C (TJ)
- Rds On (Max) @ Id, Vgs
- 12mOhm @ 500mA, 10V
- Series
- PolarP™
- Power Dissipation (Max)
- 890W (Tc)
- FET Type
- P-Channel
- Supplier Device Package
- SOT-227B
