IXTJ6N150
Transistors - FETs, MOSFETs - Single
- Manufacturer No:
- IXTJ6N150
- Manufacture:
- IXYS
- Package:
- TO-247-3
- Datasheet:
- IXTJ6N150
- Description:
- MOSFET N-CH 1500V 3A ISOTO-247
In Stock
0 pcs On sales
$9.43
Product Parameter
- Vgs (Max)
- ±30V
- Drain to Source Voltage (Vdss)
- 1500V
- Technology
- MOSFET (Metal Oxide)
- Input Capacitance (Ciss) (Max) @ Vds
- 2230pF @ 25V
- FET Feature
- -
- Current - Continuous Drain (Id) @ 25°C
- 3A (Tc)
- Part Status
- Active
- Drive Voltage (Max Rds On, Min Rds On)
- 10V
- Mounting Type
- Through Hole
- Package / Case
- TO-247-3
- Vgs(th) (Max) @ Id
- 5V @ 250µA
- Operating Temperature
- -55°C ~ 150°C (TJ)
- Rds On (Max) @ Id, Vgs
- 3.85Ohm @ 3A, 10V
- Series
- -
- Power Dissipation (Max)
- 125W (Tc)
- FET Type
- N-Channel
- Supplier Device Package
- TO-247
- Packaging
- Tube
- Gate Charge (Qg) (Max) @ Vgs
- 67nC @ 10V
