FH48-21S-0.5SV

FFC, FPC (Flat Flexible) Connectors

Manufacturer No:: FH48-21S-0.5SV
Manufacture:: Hirose Electric Co Ltd
Datasheet:: FH48-21S-0.5SV
Description:: CONN FFC VERT 21POS 0.50MM SMD

In Stock

739 pcs On sales

$3.16

Product Parameter

Mating Cycles: -

Dielectric Material: Liquid Crystal Polymer (LCP), Halogen Free

Mounting Type: Surface Mount

Number of Positions: 21

Actuator Color: Black

Current Rating (Amps): 0.5A

Cable End Type: Tabbed

Operating Temperature: -40°C ~ 85°C

Contact Finish: -

Connector/Contact Type: Contacts, Vertical - 1 Sided

Pitch: 0.020" (0.50mm)

Flat Flex Type: FFC

Contact Finish Thickness: -

Series: FH48

Voltage Rating: 50V

Material Flammability Rating: UL94 V-0

Features: Low Insertion Force (LIF)

Locking Feature: Flip Lock

Packaging: Cut Tape (CT)

Contact Material: Phosphor Bronze

Part Status: Active

Actuator Material: Liquid Crystal Polymer (LCP), Halogen Free

Termination: Solder

FFC, FCB Thickness: 0.30mm

Housing Color: Gray

Height Above Board: 0.243" (6.18mm)
